Controller Connectivity Options
At Industrial Indexing Systems, we provide various connectivity configurations to facilitate the integration of our controllers to your automation network.
From the Human Machine Interfaces (HMI) to the Programmable Logic Controllers (PLC) we leverage the strength of various communications options to coordinate and integrate IIS’s family of controller and drive products. Our connectivity options also provide commissioning and remote support of our installed base of controllers.
Various configurations include:
- TCP/IP over Ethernet
- DeviceNet Master or Slave over CAN Bus
- IIS Executive Protocol over Ethernet
- IIS Executive Protocol over Rs232
- IIS Executive Protocol over Serial USB
- Modbus RTU over RS485
- VB, C, and C# software drivers for the IIS Executive Protocol
- Sercos Automation Network
| Controller/Drive Connectivity | ||||||||
|---|---|---|---|---|---|---|---|---|
| Family | Product Type | Sercos II | Ethernet | Serial USB | Rs-232 | Rs-485 | DeviceNet | CC-link |
| Emerald Automation Controller | EMC-2100S2 | x | x(2) | x | x | x(3) | ||
| Emerald Servo Drive | ESD-xx/yCP | x | x | |||||
| Emerald EMAX Single Positioner | ESD-xx/yCP | x | ||||||
| Luminary Controller | LMC-400 | x | x | |||||
| Luminary Drive | LD-500 | x(1) | x(1) | |||||
| Luminary Drive | LD-101 | x(1) | x(1) | |||||
| X-max Single Positioner | XMax | x | x | |||||
| X-Series Servo Amp | VLASX series | x | ||||||
| X-Series Single Positioner | VLPSX series | x | x | x | x | |||
| X-Series PLC Positioner | VLNBX series | x | x | x | x | |||
Note: 1 Modbus RTU
Note: 2 TCP / IP
Note: 3 Master or Slave
| Cable Selections | |
|---|---|
| Connectivity options | Part Number |
| Sercos II | C-735xxx |
| Ethernet | C-885xxx |
| Serial USB | C-815xxx |
| Rs-232 | C-987xxx |
| Rs-485 | Belden 1348a |
| DeviceNet | Belden 1348a |
| CC-link | Belden 1348a |
